Laser 30w Stretch Marks Machine Hand Held Marking Machine Colour Laser Marking Machine
6,220.00 $
ID: 62394
Quantity
Small Logo Fiber Laser Printing Machine for Aluminium Foil 20w Raycus Fiber Laser Marking Machine
0.0 ( votes)
Price:
US $
10269.58
/ piece
Small Logo Fiber Laser Printing Machine for Aluminium Foil 20w Raycus Fiber Laser Marking Machine
Hot sale product
We care what is client care about:
1.Our fiber laser marking machine complies with CE,ISO9001, FDA standards.
2. We supply 2 years warranty service
3. We have full sets laser parts for laser marking machine in stock.
Which can ensure timely delivery and replacement for laser parts on time.
4. We train customer for machine operation at our factory for free.
5. Machine operation manual will be sent together with machine delivery.
6. Before shipment, our engineer will do machine checking within 48 continuous hours to ensure high performance and high stability.
7. We have a professional after sales service team with 5 engineers
Laser Marking Machine Description
Burn out some of the material through light energy, and show the patterns, characters, bar codes, and so on.Laser's space control and time control are very good. It has great freedom to process object's material, shape, size and processing environment. It is especially suitable for automatic processing and special surface processing. And the processing mode is flexible, which can meet the needs of the single design in the laboratory, and also meet the requirements of the industrial mass production.works well in An abominable working environment, with high tolerance to dust, shock, impact, humidity, and temperature 2.No thermoelectric cooling and water cooling, only simple air cooling.High quality and quick technical service
Laser Marking Machine can mark logo, character, serial number, bar code, data matrix on both metals and some non-metals. It does not have consumable. It’s very cost effective. It boasts fast marking speed and high marking precision. It’s widely used and well accepted in prevailing international market.
Metals: carbon steel/mild steel, stainless steel, aluminum, copper, magnesium, zinc; rare metal and alloy steel (gold,silver, titanium, etc.); special surface treatment (aluminum anodized, plating surface, surface oxygen breaking of aluminum and magnesium alloy)
Non-metals: plastics, rubber, resin, carton box, etc.
Laser Marking Machine Parameter
| Laser power | 20W
|
| Laser Wavelength | 1064nm |
| Light beam quality | <2 |
| Repeating precision | ±0.002 |
| Marking range | 110x110mm(customize) |
| Marking depth | 0.01~1mm
|
| Marking speed | 7000mm/s |
| Minimum character | 0.15mm |
| Minimum line width | 0.01mm |
| Repeating frequency | 20KHz~30KHz |
| Marking content | Graphics, text, bar codes, two-dimensional code, date, batch number, serial number |
| Graphic format supported | bmp,png,ai,dxf,dst,plt |
| working voltage | 220V±10%/50Hz/4A |
| Size | 70*71*155cm |
| Gross Weight | 145kg |
| Control interface | standard USB port
|
| Working environment | Clean and dust free or dust less |
| Laser module life | 100000~200000 hours |
| Delviery time | 3-10days |
| Type of shipping | Express,air or sea |
| Terms of payment | T/T,credit card,western union,paypal |
| package size | 80x81x165cm |
| Gross weight | 188KG |
We take part in exhibition at home and abroad. Our products are exported to India, Britain, Spain, France, Germmany, the United States, Dubai and Brazil, South Korea and other more than 100 countries and regions.
We want be a worldwide top brand of laser marking machine. We sincerely look forward to cooperate with you, warmly welcome worldwide agents to join us.
Chongqing ZiXu Machine Works has professional experience in marking machine designing and producing. We got CE, ISO9001, FDA, TUV certificate, won a large number of customers favor and approval all around the world after we continue to improve and perfect the product quality. We cooperate with many competitive enterprises at home and abroad with sincerely pre-sale and after-sales service.
- Dimensions: 77X65X145CM
- Max. Output Power: 20W
- Focal Spot Diameter: 0.15MM
- Wavelength: 1057-1070MM
- Pulse Width: 0.01MM
- Single Pulse Energy: 20 W
- Model Number: FLMM-A01
- Usage: Marking logo
- Software: Ezcad
- Colour: Blue
- Drive type: fiber laser
- Product name: Printing Machine for Aluminium Foil
- printing material: plastic
- Application: PVC ID Card
- Minimum character: 0.15mm
- Minnimum line width: 0.01mm
- power: 20w
- printing content: logo,number ,letter
